TOOLS: diamond blade for marble and granite, 250-300-350mm diameter, 25,4mm bore (not included)

MOTOR: 1-phase 2 poles 230V 50Hz 2800rpm - Power 2.2KW (3HP)

TECHNICAL FEATURES

- Galvanized work table.

- Water recycling system.

- Manual head feed.

- Tiltingheadforcuttingfrom90°to45°

- Head assembly swivelling: -45° 0° +45°

- Positive locks:: 45-22,5-0-22,5-45°

- Manual adjustment of the cutting depth

- Max. cutting depth with blade 350mm diam. 103 mm

- Max. cutting width: 280 mm

- Folding legs to facilitate transportation

MEASUREMENTS AND WEIGHT

- Overall dimensions: 956x1005x1371 mm

- Weight (empty): Kg

OPTIONAL

SIDE EXTENSION TABLE WITH ADJUSTABLE LEG 1200mm
