This is the briquetting press with excellent performances for industrial applications and production of higher quality briquettes.

Hydraulic briquetting press to press chips, grinded chips (max.10mm screen), sawdust and powder with min.-max. 8-17% moisture content. This can be mounted under silos, inside or outside filtering units.

TECHNICAL CHARACTERISTICS:

• -  basement as oil tank (complete with oil level) composed of a rectangular sturdy steel welded and powder coated frame;

• -  loading plane composed by a material’s hopper and a steel radial wheel mounted on its bottom (it rotates by means of a mechanical device and the movement of the press cylinder) to ensure the loading of the material in the box;

• -  box cylinder pre-compresses the material inside the compression chamber through the loading plane;

• -  briquettes’ cylinder compresses the material in the sleeve-extrusion pipe group;

• -  hydraulic vise in a strong and reliable steel monoblock without tie-rods mounted directly on the extrusion pipe. It

  restrains the material sliding inside the pipe and it releases it at the set pressure. An apt pressure gauge controls the

  working pressure of the vise;

• -  high quality and reliability electrovalves complete with security valve mounted directly at the rear of the press

  cylinder for a complete control of the hydraulic cycle;

• -  electromagnetic proximity switches to reduce the exchanging time of the electrovalves;
  - IP55 electrical control board complete with EATON PLC for an electronic control of the production process (working cycle, pressure, oil temperature, man/aut. cycle), an electronic stop programme with open vise for an easy morning starting;

  • -  electric motor IE2 (high efficiency) connected to the hydraulic pump to have pressure in the circuit;

  • -  closed circuit air/oil exchanger to cool down the oil in the tank, eliminating the problem of the continuous water

    consumption and the possible limestone production. It improves overall performances by optimizing the

    cooling of the machine and allowing tangible savings in the maintenance.

  • -  closed circuit refrigerator to cool down the extrusion pipe and regulate the working cycle of the vise.
